Monitor
The demand for professional-grade display performance is driving the next wave of monitor evolution. By upgrading the SoC with high-speed interface protocols and dedicated image engines, data can be processed directly at the display side, significantly reducing input lag. Localized signal processing enables high-end features like variable refresh rates (VRR), precise color calibration, and HDR rendering to be easily realized. Amlogic’s monitor SoC brings a more fluid and responsive visual experience to gaming, creative, and professional users.
Applications
All
STB
TV
MONITOR
LARGE PANEL
CAMERA
AUDIO
AIOT
xPON
CELLULAR
ROUTER
WI-FI BT COMBO
WI-FI MULTI-PROTOCAL
CLUSTER
ECUs
COCKPIT/INSTRUCTMENT
BACKBONE SWITCH
search
| SoC | Process | CPU | RX | TX | Panel | VPU | Peripheral Interface | Audio Interface | Power |
M603X1
|
22nm | RISC-V 32bit | 3D, HDMI2.1 TMDS, DP1.4 HBR3, HDCP1.4/2.3 | eDP HBR2 8lane | QHD@220Hz, FHD@300hHz | HDR10, Free-Sync, MPRT | SAR-ADC, UART, I2C, PWM, GPIO | Line out L/R, Earphone L/R, SPDIF | 3.3v/0.9v, support low power standby |
M602X1
|
22nm | RISC-V 32bit | 3D, HDMI2.1 TMDS, DP1.4 HBR2, HDCP1.4/2.3 | LVDS 4ports | FHD@240Hz, QHD@100Hz | HDR10, Free-Sync, MPRT | SAR-ADC, UART, I2C, PWM, GPIO | Line out L/R, Earphone L/R, SPDIF | 3.3v/0.9v, support low power standby |
